Firepunk 4WD 47RE F5 Transmission 1000HP+ Rated | 1996-1999 Dodge Ram 5.9 Cummins

The Firepunk F5 Transmission for your 96-99 Dodge 5.9L Cummins is built for the ultimate street truck making big power. Suited for a variety of high horsepower trucks, this transmission uses oversized shafts capable of holding extreme horsepower and torque. This is the transmission that was used in both the 1st and 2nd place trucks in the 2014 and 2015 Diesel Power Challenge. It's also the same transmission that won the Ultimate Callout Challenge in 2016, 2017 and 2018, and the one Firepunk competitors use today!

Features:

• Built For High Horsepower Applications 1000HP+
• 2-Year Unlimited Mileage, 100% Workmanship Warranty

Build List:

• Sonnax 35 Spline Fat Input Shaft
• Sonnax Billet Intermediate Shaft
• Sonnax 29 Spline Billet Output Shaft
• Custom Billet DPC Heavy Duty Triple Disc Converter (Lifetime Warranty)
• Competition Master Kit (includes added clutches in the direct drum and OD brake, OD direct clutch modification, and an oversized HD 2nd gear band)
• Billet Double Seal 2nd Gear Servo
• Billet Strut
• Billet Anchor
• Billet Accumulator Piston
• Billet Sonnax Direct Piston
• Billet 4.2 Ratio Apply Lever
• Firepunk Built High Pressure Valve Body
• Deep Pan with Drain Plug and Temp Sender Port
• Firepunk Billet SFI 29.3 Approved Flexplate

Note: The transfer case input shaft must be changed to fit the oversized output shaft.

If your model is on backorder, expect a 2-week build time before it ships. Call if you have any other questions!
